Fireproof sealing inside trough-type cable trays

Fireproof sealing inside trough-type cable trays is achieved using firestop materials, modular systems, and intumescent coatings to prevent fire and smoke propagation through walls, floors, and slabs.Key PrinciplesFireproof sealing in cable trays involves blocking gaps and penetrations where cables pass through walls, floors, or slabs to prevent fire spread. Openings must be tightly sealed without visible cracks or voids, and large openings may require a fire-resistant backing plate before sealing . The sealing must cover both internal and external gaps around the tray and cables to ensure complete fire containment .Firestop MaterialsSeveral materials are commonly used for fireproofing cable trays:Intumescent caulks and mastics: Expand when exposed to heat, sealing gaps and protecting cables from fire and smoke. Products like IC 15WB Caulk are designed for easy application with a standard caulking gun .Fire-resistant mineral wool: Often used in combination with firestop boards or packs to fill large gaps and provide thermal insulation .Firestop packs and modular systems: Pre-formed blocks or modular inserts, such as FIRSTO or Roxtec systems, allow flexible installation around multiple cables and trays, enabling easy addition or removal of cables later .Fire protection coatings and tapes: Coatings like FLAMMOTECT-A or DG-CR 0.7 form a protective shield around cables, preventing flame propagation and maintaining cable functionality during a fire .Installation PracticesModular systems: FIRSTO and Roxtec modular firestops are designed for quick assembly around cable runs, even in inaccessible openings, and can withstand mechanical loads while preventing smoke and fire spread .Packing and sealing: Firestop packs should be placed in an orderly sequence, with gaps between packs and cables not exceeding 1 cm² and a minimum packing thickness of 24 cm .Retrofit and maintenance: Some systems, like 3M Fire Barrier Moldable Putty+ or modular inserts, allow retrofitting and reuse, making it easier to add or remove cables without compromising fire protection .Environmental protection: Certain coatings and tapes also protect against UV, moisture, chemicals, and saltwater, ensuring long-term durability in industrial or outdoor installations .Compliance and SafetyFireproof sealing must comply with building codes and fire safety standards, such as UL 1479 and EN 1366, to ensure that cable tray penetrations do not compromise the fire rating of walls or floors . Proper planning and installation are critical to avoid gaps that could allow fire, smoke, or gas migration.SummaryFor trough-type cable trays, a combination of firestop caulks, intumescent coatings, mineral wool, and modular sealing systems provides effective fireproofing. Modular systems like FIRSTO or Roxtec offer flexibility, ease of installation, and compliance with fire safety standards, while coatings and caulks ensure complete encapsulation of cables. Proper installation, gap management, and adherence to standards are essential for reliable fire protection .
